Laser power :40w/50w/60w/80w/100w/130w//150w/180w
Laser type :CO2 Sealed laser tube , 10.6μm
Cooling type :Water cooling
Engraving speed: 0-60000mm/min
Cutting speed: 0-40000mm/min
Laser output control :0-100% set by software
Min. engraving size :Chinese: 2.0mm*2.0mm, English letter: 1.0mm*1.0mm
Highest scanning precision :4000DPI
Locating accuracy :≤+0.01mm
Controlling software :DSP control system
Graphic format supported :DST PLT BMP DXF DWG AI LAS,etc
Compatible software :CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.
Color separation :yes
Drive system: High-precision 3-phase stepper motor
Auxiliary equipments :Exhaust fan and air exhaust pipe
Power supply :AC110V/220V+10%,50HZ/60HZ
Working environment :Temperature:0-45C,Humidity 5-95%(No condensate water)
Packing size :according to the model
Net weight :according to the model
Option :up&down table, honeycomb worktable, rotary device, red dot position system, auto-focus device
