Description
|
Parameter
|
|
BRW1325A
|
BRW1530A
|
Option
|
|
Working Area (X*Y*Zmm)
|
1300*2500*160mm
|
1500*3000*160mm
|
According to demands
|
|
X, Y Structure
|
Rack gear
|
|
Z Structure
|
Ball Screw
|
|
Max Moving Speed
|
32000mm/min
|
|
Max Engraving Speed
|
20000mm/min
|
|
XYZ traveling positioning accuracy
|
±0.04/300mm
|
|
XYZ repositioning accuracy
|
±0.04mm
|
|
Spindle power
|
3kw/4.5kw/6kw/8kw
|
|
Spindle Speed
|
6000-24000rpm
|
|
Diameter of cutter
|
ф3.175,ф6,ф12.7
|
|
Voltage
|
AC220V,50Hz(option:AC380V,50Hz)
|
|
Drive type
|
Stepper(Option:servo)
|
|
Working Dictate
|
G Code
|
|
Operating system
|
NC-Studio(Option:Dsp System,match 3 PC software)
|
|
Interface
|
USB
|
|
Flash memory
|
128M(U Disk)
|
|
Software Compatiibility
|
Type3,Ucancam (option,Artcam Software)
|
|
Running Environment
|
Temperature: 0℃～45℃
|
|
Relative humidity: 30%～75%
|
