Features:
Integrally cast lathe bed, robust and without distortion
Three-axis transmission with imported ball screws to ensure stable and smooth movement of machine
Application of driver with high definition subdivision to ensure fast speed and high accuracy
High power spindle, brush-less, water cooling, and working vigorously with low noise and guarantees long time mass processing
Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate
Humanized design enables easy dis-assembly of machine for convenient transportation
Parameters:
Working area (X x Y x Z): 1,200 x 1,200 x 120mm
Maximum engraving speed: 6,000mm/min
Frame: cast steel
Spindle power: 1.5W (option: 2.2)
Maximum power consumption (without spindle): 1.2kW
Spindle speeds: 6,000 to 24,000rpm
Resolution: 0.005mm
Repeatability: 0.01mm
Diameter of cutter: ф3.175 (option, ф6mm)
Voltage: 220V AC/50Hz
Drive motor: stepper
Working dictate: HPGL (option, G-code)
Operating system: DSP system (match 3 PC software)
Interface: USB
Flash memory: 128MB (U-disk)
Compatible software: Type3, (Ucancam and Artcam software)
Running environment:
Temperatures: 0 to 45°C
Relative humidity: 30 to 75%
